| Keyboard: |
61 Standard-size keys, 5 octaves |
| Tones: |
242 (113 panel tones + 128 General MIDI Tones + 1 drum set) |
| Polyphony: |
32 notes maximum (16 for certain tones) |
| Main Volume: |
Adjustable |
Auto Accompaniment |
| Rhythm Patterns: |
100 |
| Chords: |
2 fingering methods (CASIO CHORD, FINGERED) |
| Rhythm Controller: |
START/STOP, SYNCHRO, FILL-IN |
| 3-step Lesson |
3 lessons (Step 1, 2, 3) |
| Playback: |
Repeat play on a single tune |
| :Lesson Part: |
Left hand, right hand |
| Evaluation Mode: |
Scoring |
| Voice Fingering Guide: |
On/Off |
Song Bank, Piano Bank |
| Number of Tunes: |
Song Bank: 50, Piano Bank 50 |
| Controllers: |
Start/Stop |
Display |
| Name display: |
TONE, RHYTHM, SONG BANK, PIANO BANK name/number, keyboard settings name/value |
| Tempo: |
Tempo vlaue, metronome, synchro standby |
| Chord: |
Chord name, Chord form |
| Fingering: |
Fingering indicators, parts |
| Staff: |
5 octaves with sharp and flat indications, pedal symbol, octave symbol |
| Keyboard: |
5 octaves |
Other Functions |
| Tempo: |
Variable (216 steps, notes = 40 to 255) |
| Transpose: |
25 steps (-12 semitones to + 12 semitones) |
| Tuning: |
Variable (A4 = approximately 440Hz +/-50 cents |
| Accompaniment/Song Bank Volume: |
Variable (100 steps, 0 to 99) |
Terminals |
| USB port: |
Type B |
| Sustain Terminal: |
Standard jack |
| Phones/Output Terminal: |
Stereo standard jack
Output Impedance: 100 ohms
Output Voltage: 4V (RMS) MAX |
| Power Supply Terminal: |
9V DC |
| Microphone In: |
Standard jack (with microphone volume slider)
Input impedance: 2k ohms
Input sensitivity: 10mV |
| Power Supply |
Dual power supply system |
| Batteries: |
6 AA-size batteries |
| Battery Life: |
Approximately 4 hours continuous operation on alkaline batteries
Approximately 2 hours continuous operation on manganese batteries |
| AC Adaptor: |
AD-5 |
| Auto Power Off: |
Turns power off approximately 6 minutes after last key operation. Enabled under battery power only, can be disabled manually. |
| Speaker Output: |
2.0W + 2.0W |
| Power Consumption: |
9V...7.7W |
| Dimensions: |
95.6 x 35.6 x 13.3cm (37 11/16 x 14 1/16 x 5 1/4 inch) |
| Weight: |
Approximately 4.0kg (8.8lbs) (without batteries) |
